DMG GILDEMEISTER CTX ALPHA 500SOLD
SOLD
- Reference Number
- 22086
- Year of Manufacture
- 2013
- control
- Heindenhain CNC-Pilot 640
- max. turning/swing diamter
- 240 mm/500 mm
- max. turning length
- 470 mm
- main spindle
- motor output: 27/20 kW
max. spindle speed: 5.500 rpm
max. bar capacity: 65 mm - sub spindle
- motor output: 16,2/12,6 kW
max. spindle speed: 6.000 rpm
part hollow clamping device, drawtube diameter: 37 mm - tool turret
- - 12-station turret with high presicion interface Trixfix
- 12 driven tool stations
- Milling drive DIN69880
- max. speed: 5.000 rpm - movements
- X-axis: 190 mm
Y-axis: 80 mm
Z-axis: 520 mm - other options
- - Direct scale X-axis
- Differential pressure clamping sub spindle
- Coolant pump 12 bar
- Interface for barfeeder (Saco, Irco Breuning, LNS)
- Parts catcher incl. parts conveyor, Ø65x185 mm, 3 kg
- Machine window cleaning with air
- swarf conveyor - other equipment
- - 1 x collet chuck Hainbuch Spanntop nova Kombi axzug 65, main spindle
- 1 x collet chuck Hainbuch Spanntop nova Kombi axzug 65, sub spindle
- 4 x driven toolholders, angular double sided, quick change system Varia VX (Trixfix)
- 4 x driven toolholders, straight, quick change system Varia VX (Trixfix)
10 x collets ER25 for Varia VX
- 6 x VDI30 D1 OD turning holder
- 6 x bor holders (Trixfix)
- 1 x cutt off holder
- 1 x bar gripper - machining hours
- Power on: approx. 18.000 h
Cutting time: approx: 8.600 h
