MAZAK INTEGREX i-300 (1500U)

Title:

Description:

MAZAK INTEGREX i-300 (1500U)CNC-Lathe

New machine - mfg. year 2021
Reference Number
23031
Year of Manufacture
New machine - mfg. year 2021
control
Smooth X
max. turning diameter
658 mm

max. turning length
1.519 mm
main spindle
motor output: 30 kW
max. spindle speed: 4.000 rpm
C-axis
max. bar capacity: 80 mm
spindle nose: A2-8
milling spindle
milling spindle 24 kW (Oil-air-lubrication) (Option MR372)
max. spindle speed 12.000 rpm
HSK63
movements
X-axis: 615 mm
Y-axis: 250 mm
Z-axis: 1.585 mm
W-axis: 1.574 mm
B-Achse: -30°-210°
tool magazine / ATC
110 tools
max. tool diameter: 90/125 mm
max. tool length: 400 mm
max. tool weight: 12 kg
other options
- NC-tailstock with live center MT5
- Workpiece stop in spindle (B-210A815X) (Option SO052)
- Air at milling spindle (Option CS173)
- Air at tailstock quill (Option TT080)
- Internal cooling ballscrew in Y and Z axis (Option MO553)
- Shower collant (Option CS256)
- Interface Europe 70 bar (Option CS808)
- Signal lamp (Option PL083)
- Automatic door (Option AS321)
- Hyfraulic temperature regulation (Option MO115)
- linear scales for Z-axis of milling spindle (B-axis) (Option SF030)
- linear scales for X and Y axis (Option SF050)
- preparation Mazak Monitoring B Renishaw RMP60 (Option MB267)
- Renishaw NC-4 Tool Laser (Option A12J00001)
- Preparation for Multi & Flashtool System (Option TE810)
- Overload detection (Option AS080)
- Mazak API (Option NO056)
- Smooth Synchr. Mill/Tapp (Option NO066)
- Tool radius compensation – 5 axis (Option NO0123)
- Engraving function (Option NO127)
- Tool cutting point control (Option NO128)
- G00 slope constant (NO0442)
- Cylinder + polar interpolation (NO559)
- Tool length compensation in tool axis direction (NO611)
- 5-axis-package for Smooth X (Option NP326)
- Visiport (Option A12J00011)
- Swarf conveyor Knoll (Option DECV784)
- Knoll coolant system KF400/2300 (Option DECV001)
+70 bar pump, 7 pressure levels
+ 2.300 Liter Tank
+Paper belt filter
- Preparation for mist extractor (Option CS666)
- Mist extractor Losma GX1000 (Option CS626)
- G-Clipper for Losma mist extractor (Option CS691)
equipment
- 40. off HSK63 toolholders
- Big clamping package – Hainbuch (worth €61.725)
+Centrotex adapter
+Hainbuch collet chuck
+Div. collets
+3-jawchuck , Diameter 315 mm
+A lot more clamping equipment
dimensions and weight
L/B/H: 4.910/2.800/2.720mm
16.300 kg
New machine Mazak Integrex i-300 for sale.
Price on request. Immediate delivery.
