MAZAK QT NEXUS 200-II MSY

Title:

Description:

MAZAK QT NEXUS 200-II MSYSOLD!

SOLD! 2008 - Matrix - barfeeder interface - parts catcher - 70 bar
Reference Number
22045
Year of Manufacture
2008
Control
Mazatrol Matrix
Max. turning diameter
380 mm

Max. turning length
575 mm
movements
X-axis: 230 mm
Y-axis: 100 mm
Z-axis: 575 mm
W-axis: 585 mm
rapid travel
X/Y/Z 30/21/33 m/min
main spindle
motor output: 26 kW
max. spindle speed: 5.000 rpm
max. torque: 465 Nm
spindle nose: A2-6
spindle bore: 76 mm
max. bar capacity 65 mm
3-hjawchuck Kitagawa BB208
sub spindle
motor output: 11 kW
max. spindle speed 6.000 rpm
3-jawchuck Kitagawa B206
tool turret
16 stations turret
16 driven tool stations
milling drive motor output: 5,5 kW
max. speed: 4.500 U/min
coolant system
separate coolant tank
paper band filtration
70 bar high pressure pump, Grundfos
swarf conveyor
right side
other options
Tooleye
parts catcher
interface for barfeeder
C-axis for main and sub spindle
