MAZAK VTC-800/20SRVENDU
Année 2016
- numéro de réference
- 23055
- Année de construction
- 2016
- Armoire
- Matrix 2
5 axe continus - Course
- X-Achse: 2.000 mm
Y-Achse: 800 mm
Z-Achse: 720 mm
B-Achse: 220°
C-Achse: 360°
- table
- table size: 2.500 mm x 820 mm
- Poids admissible sur table
- 1.700 kg
- Broche de fraisage
- Puissance de broche: 35kW
Vitesses de broche: 18.000 tr/min
SK40 - Changeur d'outils
- Capacité du magasin d'outils : 30
- Equipment
- - arrosage 15 bars
- preparation 70 bars
- NC-rotary table (Mazak),
Diameter 500 mm,
360.000 positions
- Clamping device for NC-rotary table in horizontal postition
- Tool length measuring
- Mazak Monitoring System B, Renishaw RMP 60 probe
- Air blow spindle
- Partition wall for
pendulum machining
- Electronic handwheel
- swarf conveyor
- 5-axis Software-Pakage
NO116 5-axis simultaneous – EIA/ISO
NO117 Tool Tip Control – 5-axis simultaneous
NO443 Mazaacc-2D – Shape compensation
NO444 High Speed
NO445 Shape compensation for rotary axis
NO497 Smoothing control
NO487 5-axis Spline-Interpolation
