MAZAK INTEGREX I-800V/8S5-Achsen Multifunktionsmaschine in Vertikalausführung mit Drehfunktion
Smooth X - 120 Werkzeugplätze - 15.000 U/min - HSK-T100 - 5-Achsen Simultanbearbeitung - Renishaw RMP 600 - Flash Tool - 70 bar IKZ
- Referenznummer
- 22047
- Baujahr
- 2021
- Steuerung
- Mazatrol Smooth X
5-Achsen Simultanbearbeitung - Verfahrwege
- X-Achse: 1.700 mm
Y-Achse: 1.665 mm
Z-Achse: 1.150 mm
B-Achse: 150° (-30° bis ++120°)
C-Achse: 360°
- max. Werkstückdurchmesser
- 1.700 mm
- NC-Rundtisch
- Antriebsleistung: 45 kW
Max. Drehmoment: 3.120 Nm
max. Drehzahl: 500 U/min
C-Achse 0.0001°, 50 U/min
Ø1.000 mm Rundpalette mit Gewindebohrungen und Zentrierbohrung
Glasmaßstab C-Achse - Frässpindel
- Antriebsleistung: 56/45 kW
max. Drehzahl: 15.000 U/min
HSK-T100
B-Achse 0.0001° - Werkzeugmagazin
- 120 Werkzeugplätze
Max. Werkzeugdurchmesser: 125/250 mm
Max. Werkzeuglänge: 650 mm
Max. Werkzeuggewicht: 30 kg - Kühlmittelsystem und Späneförderer
- Cromar Series IV 70 bar Späneförderer System
Vergrößerter Kühlmitteltank
Cromar Kühlmitteltemperierung - weitere Ausstattung
- Ölnebelabsaugung
Integrated Camera Spin Window & Kühlmittelpistole
manuelles Handrad
Luftausblasung Werkstück
Mazak NC Gage multi-tasking paket
Renishaw RMP 600 System - Softwareoptionen
- TE809 Preparation for Flash Tool
TE008 Stopper block for angle tool holder
NO443 B) Mazacc 2D software (shape compensation)
NO444 D) Mazacc 3D high speed software package
NO445 B) Shape compensation for rotary axes
NO497 D) High smoothing control (requires Mazacc 3D)
Seamless corner control
Variable acceleration control
Ultra high speed machining mode
Rapid overlap
NO098 EIA/ISO code input function (standard)
NO139 Additional EIA/ISO functions (requires EIA/ISO)
NO483 Thread cutting function
NO142 Inverse time feed
NO509 Polar coordinates input (EIA)
NO144 Sequence number comparison stop function
NO481 Additional workpiece coordinate system 300 pairs
NO051 User macro (common variables: 600 pairs)
NO075 Mazak tapping/boring tornado (EIA/ISO)
NO516 EIA pattern cycle (grid, arc)
NO149 Tilted working plane
NO056 Mazak API
NO059 MT connect adapter
NO066 Smooth synchronised tapping (milling spindle)
NO116 F) EIA/ISO function simultaneous 5 axes
NO117 F) Tool tip point control/simultaneous 5 axes
NO123 F) Tool radius compensation/5 axis
NO127 Engraving function
NO128 Tool cutting point control
NO159 Maximum porgamm size: 32MB
NO391 Additional M-code one set (2 M-codes)
NO464 Ethernet operation function
NO482 Re-threading
NO599 B) Cylindrical and polar co-ordinate
NO610 Work setting error compensation
NO611 Tool length compensation in tool axis direction
