MAZAK INTEGREX I-800V/8
Ar 2017
- Referensnummer
- 24008
- År
- 2017
- Styrning
- Mazatrol Smooth X
5-axlig simultan
- Rörelse
- X-axel: 1.700 mm
Y-axel: 1.500 mm
Z-axel: 1.150 mm
B-axel: 150° (-30° bis ++120°)
C-axel: 360° - max. detaljdiameter
- 1.700 mm
- NC bord
- max. varvtal: 500 v/min
C-axel 0.0001°, 50 U/min - Frässpindel
- max. Spindelvarvtal: 5.000 v/min
B-axel 0.0001°
Capto C8 - verktygsmagasin
- 80 verktygsplatser
max. verktygsdiameter: 125/250 mm
max. verktygslängd: 650 mm
max. verktygsvikt: 30 kg
Tool ID magazine panel - utrustning
- - Tool-ID
- Energy dashboard function
- Man. pulsegenerator
- Airblow at workpiece
- Coolant temperature control system
- Superflow V30C-J
- Laser mill tool measure (NC4/full, no software) including tooleye
- Dia. 1000 mm Chuck
- Swarfconveyor CONSEP 1
- Multitoolfunction
- Hobbing function
- Mazak API
- Rigid tapping
- Spindle shaper type operation
- Extended memory 32 MB
- G00 slope constant
- Cylindreical and polar co-ordinate
- Tool length compensation in tool axis direction
- Smooth Gear Milling
- 5 axis machining package for Smooth X
- Orbiturn
- High torque milling spindle with scale feedback, max 5.000 rpm
- Smooth Gear Skiving
- Large volume coolant
- MT Connect adaptor
- Prep. for Renishaw Sprint
- Renishaw probe RMP 600 - timmar
- 4.000 skärtimmar
- Begagnad Mazak Integrex i-800V/8 till salu.
- Pris pa farfragan. Ledig omgaende.
