MAZAK VTC-800/20SRSåld
År 2016
- Referensnummer
- 23055
- År
- 2016
- Styrning
- Matrix 2
5-axlig simultan - rörelse
- X-axel: 2.000 mm
Y-axel: 800 mm
Z-axel: 720 mm
B-axel: 220°
- bordsstorlek
- 2.500 mm x 820 mm
- Max bordsbelastning
- 1.700 kg
- Frässpindel
- Spindeleffekt: 35 kW
max. Spindelvarvtal: 18.000 v/min
SK-40 - Verktygsmagasin / ATC
- 30 positioner
- Utrustning
- - Spantransportör
- 15 bar pump
- förbered för 70 bar
- Mazak Monitoring System B, Renishaw RMP60- NC-rotary table (Mazak),
Diameter 500 mm,
360.000 positions
- Clamping device for NC-rotary table in horizontal postition
- Tool length measuring
- Mazak Monitoring System B, Renishaw RMP 60 probe
- Partition wall for
pendulum machining
- Electronic handwheel
- swarf conveyor
- 5-axis Software-Pakage
NO116 5-axis simultaneous – EIA/ISO
NO117 Tool Tip Control – 5-axis simultaneous
NO443 Mazaacc-2D – Shape compensation
NO444 High Speed
NO445 Shape compensation for rotary axis
NO497 Smoothing control
NO487 5-axis Spline-Interpolation
